New 2026 Chevrolet Express ls Front-wheel drive Van
- VIN: 1GAZGNFP8T1264823
- Stock:
Basic Info
-
Exterior:White
-
Drivetrain:Front-wheel drive
-
Interior:medium dark pewter
-
Transmission:Automatic
-
Engine:4.3 L
Key Features
-
Backup Camera
-
Rear A/C
-
Side-Impact Air Bags
Description
Vehicle Details
Exterior
- Tires, front LT245/75R16E all-season, blackwall
- Tires, rear LT245/75R16E all-season, blackwall
- Tire, spare LT245/75R16 all-season, blackwall
- Body, standard
- Door, swing-out passenger-side, 60/40 split
- Bumpers, front and rear painted Black with step-pad
- Grille, Black composite
- Headlamps, dual halogen composite,
- Mirrors, outside heated power-adjustable, Black, manual-folding
- Glass, Solar-Ray deep-tinted (all windows except light-tinted glass on windshield and driver- and front passenger-side glass)
- Glass, swing-out side door windows
- Glass, swing-out rear cargo door windows
- Glass, enhanced-technology, rearmost side windows. 3-layer special glass is designed to help reduce the risk of ejection during a crash
- Glass, full-body window package (Includes (A18) swing-out rear cargo door window glass and (A19) swing-out side door window glass.)
- Wipers, front intermittent wet-arm with pulse washers
- License plate kit, front
Interior
- Console, engine cover with open storage bin
- Cup holders, 3 on the engine console cover
- Floor covering, full-length Black rubberized-vinyl
- Steering wheel, steel sleeve column with theft-deterrent locking feature, Black
- Instrumentation, analogue with speedometer, odometer with trip odometer, fuel level, voltmeter, engine temperature and oil pressure
- Oil life monitor
- Warning tones, headlamp on and key-in-ignition
- Compass, 8-point digital located in the Driver Information Centre
- Theft-deterrent system, vehicle, PASS-Key III
- Heater, rear auxiliary
- Defogger, front and side windows
- Headliner, cloth
- Visors, driver and front passenger, padded with cloth trim and dual vanity mirrors, illuminated on passenger-side
- Assist handles, driver and right-front passenger
- Lighting, interior with 2 dome lights, defeat switch and door handle-activated switches
- Lighting, auxiliary with reading lights
Mechanical
- Engine, 4.3L V6 with Direct Injection and Variable Valve Timing includes aluminum block construction (276 hp [206 kW] @ 5200 rpm, 298 lb-ft of torque [404 Nm] @ 3900 rpm) (Reference the Engine/Axle page for availability.)
- Rear axle, 3.42 ratio (Reference the Engine/Axle page for availability.)
- GVWR, 9600 lbs. (4354 kgs) (Reference the Engine/Axle page for availability.)
- Cold Climate Package (Includes (K05) engine block heater.)
- Engine block heater
- Tow/haul mode selector, instrument panel-mounted
- Rear wheel drive
- Cooling, external engine oil cooler
- Battery, 600 cold-cranking amps, maintenance-free with rundown protection and retained accessory power
- Alternator, 150 amps
- Frame, ladder-type
- Suspension, front independent with coil springs and stabilizer bar
- Suspension, rear hypoid drive axle with multi-leaf springs
- Steering, power,
- Brakes, 4-wheel antilock, 4-wheel disc
- Fuel tank capacity, mid-frame and approximately 31 gallons (117.3L)
- Exhaust, aluminized stainless steel muffler and tailpipe
Safety
- StabiliTrak, traction assistance and vehicle stability enhancement system
- Brake/transmission shift interlock, for automatic transmissions
- Hill Start Assist
- Door beams, steel-side
- Airbags, seat-mounted side-impact for driver and right-front passenger and roof-rail mounted head-curtain provides coverage for outboard seating positions for first 3-rows only. Enhanced-technology glass is provided for fourth row with (ZX5) 12-passenger seating and fourth and fifth rows with (ZP3) 15-passenger seating
- OnStar services capable (Currently not available to order. See onstar.ca for details and limitations. Services vary by model. Service plan required.)
- Child seat anchors all three passenger rear seats have two anchors for outboard seating positions and tethers for two seating positions. See the Owner's Manual for more information
Tech Specs
- Vehicle Name: Chevrolet Express Passenger
- Body Style: Passenger Van
- Body Code: ZW9
- Drivetrain: Rear Wheel Drive
- Passenger Capacity: 12
- Gross Axle Wt Rating - Front: 4300
- Gross Axle Wt Rating - Rear: 6084
- Curb Weight - Front: 3189
- Curb Weight - Rear: 2984
- Gross Vehicle Weight Rating Cap: 9600
- EnerGuide Estimate - Combined:
- EnerGuide Estimate - City:
- EnerGuide Estimate - Hwy:
- G/km Of CO2 Emissions:
- Gross Combined Wt Rating: 15000
- Dead Weight Hitch - Max Trailer Wt.: 5000
- Dead Weight Hitch - Max Tongue Wt.: 500
- Wt Distributing Hitch - Max Trailer Wt.: 6300
- Wt Distributing Hitch - Max Tongue Wt.: 630
- Fifth Wheel Hitch - Max Trailer Wt.:
- Fifth Wheel Hitch - Max Tongue Wt.:
- Engine Order Code: LV1
- Engine Type: Gas V6
- Displacement: 4.3L/262
- Fuel System: Direct Injection
- SAE Net Horsepower @ RPM: 276 @ 5200
- SAE Net Torque @ RPM: 298 @ 3900
- Trans Order Code: MTH
- Trans Type: 8
- Trans Description Cont.: Automatic
- Trans Description Cont. Again:
- First Gear Ratio (:1): - TBD -
- Second Gear Ratio (:1): - TBD -
- Third Gear Ratio (:1): - TBD -
- Fourth Gear Ratio (:1): - TBD -
- Fifth Gear Ratio (:1): - TBD -
- Sixth Gear Ratio (:1): - TBD -
- Seventh Gear Ratio (:1): - TBD -
- Eighth Gear Ratio (:1): - TBD -
- Reverse Ratio (:1): - TBD -
- Clutch Size:
- Trans Power Take Off:
- Trans PTO Access:
- Transfer Case Model:
- Transfer Case Gear Ratio (:1), High:
- Transfer Case Gear Ratio (:1), Low:
- Transfer Case Power Take Off:
- Cold Cranking Amps @ 0° F (Primary): 600
- Cold Cranking Amps @ 0° F (2nd):
- Maximum Alternator Capacity (amps): 150
- Maximum Alternator Watts: N/A
- Total Cooling System Capacity: - TBD -
- Engine Oil Cooler: Yes
- Frame Type: Ladder-Type
- Suspension Type - Front: Independent w/Coil Springs
- Suspension Type - Rear: Hypoid Multi-Leaf
- Spring Capacity - Front: 4300
- Spring Capacity - Rear: 6084
- Axle Type - Front: Independent
- Axle Type - Rear: Full-Floating
- Axle Capacity - Front: 4300
- Axle Capacity - Rear: 6084
- Axle Ratio (:1) - Front:
- Axle Ratio (:1) - Rear: 3.42
- Shock Absorber Diameter - Front: N/A
- Shock Absorber Diameter - Rear: N/A
- Stabilizer Bar Diameter - Front: 1.38
- Stabilizer Bar Diameter - Rear:
- Front Tire Order Code: XLP
- Rear Tire Order Code: YLP
- Spare Tire Order Code: ZLP
- Front Tire Size: LT245/75R16E
- Rear Tire Size: LT245/75R16E
- Spare Tire Size: LT245/75R16
- Front Tire Capacity: 3042
- Rear Tire Capacity: 3042
- Spare Tire Capacity: - TBD -
- Revolutions/Mile @ 45 mph - Front: N/A
- Revolutions/Mile @ 45 mph - Rear: N/A
- Revolutions/Mile @ 45 mph - Spare: N/A
- Front Wheel Size: 16 x 6.5
- Rear Wheel Size: 16 x 6.5
- Spare Wheel Size: 16 x 6.5
- Front Wheel Material: Steel
- Rear Wheel Material: Steel
- Spare Wheel Material: Steel
- Steering Type: Pwr
- Steering Ratio (:1), On Centre: - TBD -
- Steering Ratio (:1), At Lock: - TBD -
- Turning Diameter - Curb to Curb: - TBD -
- Turning Diameter - Wall to Wall: N/A
- Brake Type: Pwr
- Brake ABS System: 4-Wheel
- Brake ABS System (Second Line):
- Disc - Front (Yes or ): Yes
- Disc - Rear (Yes or ): Yes
- Front Brake Rotor Diam x Thickness: 12.8 x 1.5
- Rear Brake Rotor Diam x Thickness: 13.0 x 1.1
- Drum - Rear (Yes or ):
- Rear Drum Diam x Width:
- Fuel Tank Capacity, Approx: 117
- Aux Fuel Tank Capacity, Approx:
- Fuel Tank Location: Mid-Frame
- Aux Fuel Tank Location:
- Front Head Room: 40.85
- Front Leg Room: 41.35
- Front Shoulder Room: 68.85
- Front Hip Room: 65.48
- Second Head Room: 38.42
- Second Leg Room: 36.3
- Second Shoulder Room: 68.6
- Second Hip Room: 65.62
- Third Head Room: 38.5
- Third Leg Room: 36.58
- Third Shoulder Room: 65.75
- Third Hip Room: 63.25
- Fourth Head Room: 38.3
- Fourth Leg Room: 36.58
- Fourth Shoulder Room: 69.1
- Fourth Hip Room: 65.65
- Fifth Head Room:
- Fifth Leg Room:
- Fifth Shoulder Room:
- Fifth Hip Room:
- Wheelbase: 155.1
- Length, Overall: 243.95
- Width, Max w/o mirrors: 79.25
- Height, Overall: 84.7
- Overhang, Front: 39.68
- Overhang, Rear w/bumper: - TBD -
- Ground to Top of Load Floor: 32.2
- Ground Clearance, Front: 9.45
- Ground Clearance, Rear: 8.6
- Rear Door Type: Swing-Out
- Rear Door Opening Height: 47.2
- Rear Door Opening Width: 53.42
- Side Door Type: Swing-Out
- Side Door Opening Height: 46.7
- Side Door Opening Width: - TBD -
- Step Up Height - Front: 27.25
- Step Up Height - Side: 27.85
- Cargo Area Length @ Floor to Console: 173.65
- Cargo Area Length @ Floor to Seat 1: 146.05
- Cargo Area Length @ Floor to Seat 2: - TBD -
- Cargo Area Length @ Floor to Seat 3: - TBD -
- Cargo Area Length @ Floor to Seat 4: - TBD -
- Cargo Area Width @ Beltline: - TBD -
- Cargo Box Width @ Wheelhousings: 50.9
- Cargo Box (Area) Height: 51.8
- Cargo Volume to Seat 1: 255.5
- Cargo Volume to Seat 2: - TBD -
- Cargo Volume to Seat 3: - TBD -
- Cargo Volume to Seat 4: - TBD -
- Model Group: Express
- Vehicle Segment: Large Van
- Vehicle Type: Extended Passenger Van
- Body Cab Style: Extended Passenger Van
- Engine Displacement Units: 4.3
- Engine Camshaft: OHV
- Engine Block Type: aluminum
- Engine Cylinder Count: 6
- Engine Valve Count: 2
- Country of Origin: United States Chevrolet Active
Details
- Driver Air Bag
- Passenger Air Bag
- Passenger Air Bag On/Off Switch
- Front Side Air Bag
- Front Head Air Bag
- Rear Head Air Bag
- A/C
- Rear A/C
- AM/FM Stereo
- ABS
- 4-Wheel Disc Brakes
- Cruise Control
- Rear Wheel Drive
- V6 Cylinder Engine
- Gasoline Fuel
- Power Door Locks
- Heated Mirrors
- Power Mirror(s)
- Bucket Seats
- Power Steering
- Adjustable Steering Wheel
- Tires - Front All-Season
- Tires - Rear All-Season
- Conventional Spare Tire
- Traction Control
- Power Windows
- Intermittent Wipers
- A/T
- MP3 Capability
- Privacy Glass
- Power Outlet
- Immobilizer
- Driver Vanity Mirror
- Passenger Vanity Mirror
- Passenger Illuminated Visor Mirror
- Transmission w/Dual Shift Mode
- Transmission Overdrive Switch
- Tire Pressure Monitor
- Trip Computer
- Steel Wheels
- 8-Speed A/T
- Back-Up Camera
- Stability Control
- Auxiliary Audio Input
- Requires Subscription
